The drawing set: our own jobs, sheet by sheet

These are photos from Apex jobs, taken on the job. They are laid out the way a plan set is: mechanical rooms first, then radiant and hydronic work, then kitchens and baths. Each one has a sheet number and a plain description of what you are looking at.

Phone (509) 575-0148 if you have a job like one of these.

Series M · Mechanical

Mechanical rooms and commercial

Water heaters, softeners, filtration, risers, pumps and an eye wash station. Commercial piping photographs well because it is built to be looked at, serviced and trusted.

Mechanical room with twin commercial water heaters, water softener tanks and insulated white piping overhead — Sheet M-101 · Twin commercial water heaters, softener and insulated piping

Wider view of the same mechanical room showing the water heaters, softener, insulated piping and floor drain — Sheet M-102 · The same room, wider, with the floor drain in view

Two black water heaters plumbed with copper and PEX beside blue whole-house filter canisters on plywood — Sheet M-103 · Two water heaters in copper and PEX, filter canisters alongside

Green painted piping risers, copper and blue valves with a pump on a concrete pad — Sheet M-104 · Painted risers, copper and a pump on its pad

Green piping risers with a copper manifold, meters and blue gate valves on a white wall — Sheet M-105 · Risers, copper manifold, meters and gate valves

Job note

Most plumbing ends up closed in behind drywall, ceilings or concrete. A mechanical room is the one place the whole system stays in view, so every valve, riser and run is there to be looked at and serviced.

More of this is on our commercial plumbing page, including water heaters, boilers, gas piping and air piping.

Green emergency shower and eye wash station installed on an exterior wall — Sheet M-106 · Emergency shower and eye wash station on an exterior wall

Series H · Hydronic

Radiant and hydronic

A warehouse floor of radiant PEX before the pour, and the manifolds that feed those loops. Heat that runs through the slab starts as this pattern of tubing.

Warehouse floor covered in serpentine radiant PEX loops laid over insulation board before the pour — Sheet H-101 · Radiant loops across a warehouse slab, before the pour

Two radiant manifolds mounted on plywood with dozens of PEX loops dropping to the slab — Sheet H-102 · Two manifolds, every loop running to the slab

Job note

Radiant tubing goes down before the concrete does. After the pour, these loops are the last thing anyone sees of the system, which is why the layout on the floor matters more than anything you can photograph afterward.

Radiant floors, hydronic heating and snowmelt all live on one page: hydronic and radiant heating.

Close view of the same two radiant manifolds and their PEX loops on plywood — Sheet H-103 · The same manifolds, closer

Series P · Plumbing fixtures

Kitchens and baths

Farmhouse sinks, vanities, tubs, showers and toilets. Finish work in a home, with the rough plumbing behind it done to match.

Stainless farmhouse sink with a pull-down faucet under a window, tile backsplash and quartz counter — Sheet P-101 · Stainless farmhouse sink with a pull-down faucet

Farmhouse sink between dark cabinets with a dishwasher beside it — Sheet P-102 · Farmhouse sink and dishwasher between dark cabinets

Square stainless utility sink set into a quartz counter with a brushed nickel faucet — Sheet P-103 · Square stainless utility sink in quartz

White undermount vanity sink with a brushed faucet on a quartz top — Sheet P-104 · Undermount vanity sink, brushed faucet

Double vanity with dark shaker cabinets and two faucets — Sheet P-105 · Double vanity, two faucets

Elongated toilet beside a dark vanity on a tile floor — Sheet P-106 · Elongated toilet beside a dark vanity

Toilet in a bathroom finished with bands of tile — Sheet P-107 · Toilet in a banded-tile bathroom

Freestanding soaker tub with a deck-mounted filler in marble-look tile — Sheet P-108 · Freestanding soaker tub, deck-mount filler

Custom shower with a hand shower on a slide bar and two valve trims in banded grey and white tile — Sheet P-109 · Hand shower on a slide bar, two valve trims

Square rain shower head and body spray in banded tile — Sheet P-110 · Square rain head and body spray, same shower

Clawfoot slipper tub in a bathroom with subway tile and a hex tile floor — Sheet P-111 · Clawfoot slipper tub, subway tile, hex floor

Freestanding tub with a floor-mount filler beside a reclaimed-wood wall, job in progress — Sheet P-112 · Freestanding tub mid-install beside a reclaimed-wood wall

Job note

Sinks, tubs, showers and toilets are the fixtures you see. The supply lines, valves and drains behind them are the part that has to be right.

Homeowners can read more on residential plumbing.
